| Arabirim | • 9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ Ports)
• AUTO Negotiation
• AUTO MDI/MDIX |
|---|
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) |
|---|
| Fan Sayısı | Fanless |
|---|
| Kurulum | • Desktop
• Wall Mounting |
|---|
| Güç Kaynağı | External Power Adapter (Output: 53.5VDC / 1.31A) |
|---|
| PoE Portları (RJ45) | • Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–8, up to 30 W PoE output per port
• Power Supply: 63 W |
|---|
| LED Göstergesi | • Power
• Link/Act
• PoE Status
• PoE MAX |
|---|
| Boyutlar ( W X D X H ) | 6.7×3.9×1.1 in (171×98×27 mm) |
|---|
| Maks. Güç Tüketimi | • 3.67 W (220 V/50 Hz no PD connected)
• 73.24 W (220 V/50 Hz with 63 W PD connected) |
|---|
| Max Heat Dissipation | • 12.48 BTU/h (220 V/50 Hz no PD connected)
• 249 BTU/h (220 V/50 Hz with 63 W PD connected) |
|---|
