| Arabirim | • 6× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af PoE Ports)
• AUTO Negotiation
• AUTO MDI/MDIX |
|---|
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) |
|---|
| Fan Sayısı | Fanless |
|---|
| Kurulum | • Desktop
• Wall Mounting |
|---|
| Güç Kaynağı | External Power Adapter (Output: 53.5VDC / 0.81A) |
|---|
| PoE Portları (RJ45) | • Standard: 802.3 af compliant
• PoE Ports: Ports 1–4, up to 15.4 W PoE output per port
• Power Supply: 41 W |
|---|
| LED Göstergesi | • Power
• Link/Act
• PoE Status
• PoE MAX |
|---|
| Boyutlar ( W X D X H ) | 6.2×4.0×1.0 in (158×101×25 mm) |
|---|
| Maks. Güç Tüketimi | • 2.53 W (220 V/50 Hz no PD connected)
• 47.76 W (220 V/50 Hz with 41 W PD connected) |
|---|
| Max Heat Dissipation | • 8.61 BTU/h (220 V/50 Hz no PD connected)
• 162.38 BTU/h (220 V/50 Hz with 41 W PD connected) |
|---|
